| Parameter | Value |
|---|---|
| Input voltage | 415Vac ± 10%, 50 Hz, |
| Input power factor | 0.93 |
| Output voltage | 0.5V – 12 V variable (under 5% or more loaded condition) |
| Output current | 30-1000A @ rated load resistance |
| Voltage regulation | < 0.5% for ±10% variation in line voltage |
| Load regulation | < 0.5% for 50% to 100% variation in output current |
| Duty cycle | Continuous |
| Protections | Line Over Voltage, and Output Over Current, Over Temperature |
| Ripple factor | < 2% at full load |
| Current/Voltage stability | 0.5% for ambient temperature of 35 deg centigrade after 1 hour of operation |
| Current monitoring | 3 ½ digit DPM |
| Voltage Monitoring | 3 ½ digit DPM |
| Cooling | Forced air cooling |
| Size | 600 mm (W) x 400mm (H) x 370 mm(D) |
| Weight | 40 kg |
