| Parameter | Value |
|---|---|
| Output Voltage | 0-20 V DC maximum |
| Output Current | 500 A maximum |
| Control action | Current controlled |
| Line voltage | 3 Phase, 415 Vac, 50 Hz |
| Power factor | 0.93 |
| Stability | 0.2% for 8 hour after 2 hours of warm up. |
| Line regulation | >0.2% |
| Load regulation | > 0.2% |
| Noise and ripple | ≤ 0.5% rms |
| Remote/Local controls | ON/OFF, Fault Reset, Current Set, Remote /Local, Current increase/decrease |
| Protections | Line over voltage, and Output over current, Over temperature |
| Back panel BNC connectors for monitoring | Current Read back : 0-10V Voltage Read back : 0-10V |
| Programming | Fully programmable via digital interface RS 485 port |
| Cooling | Forced air cooling |
| Weight | 30 kg |
| Size | 480 mm (W) x 380mm (H) x 520 mm(D) |
